Specifications
Performance
Frequency Range (-10 dB)
70 Hz – 20 kHz
Horizontal Coverage (-6 dB)
90º
Vertical Coverage
90º
Nominal Impedance
8 ohms
Transformer Taps 70 V
12.5 W – 25 W – 50 W – 100 W
Transformer Taps 100 V
25 W – 50 W – 100 W
RMS Power Handling
150 W
Peak Power Handling
600 W
On-axis Sensitivity 1W/1 m
94 dB SPL
Maximum Peak SPL at 1 m
122 dB
Recommended Amplifier
INTEGRAL-A402 INTEGRAL-A1002 INTEGRAL-A1004
Connectivity
Audio Input Connector
Covered Barrier Strip Terminals
Audio Output Connector
Spring Terminals
Audio
LF Driver
8GV
HF Driver
M-32
Construction
Enclosure Construction
Polypropylene
Enclosure Geometry
Trapezoidal
Rigging
M8 Rigging Points
Color
Black
Dimensions
Enclosure Dimensions (H x W x D)
480 x 280 x 260 mm 18.9" x 11.0" x 10.2"
Carton Dimensions (H x W x D)
550 x 350 x 340 mm 21.6" x 13.8" x 13.4"
Weight
Net Weight
8.5 kg (18.7 lbs)
Shipping Weight
12.0 kg (26.5 lbs)
