Specifications
Performance
Frequency Range (-10 dB)
60 Hz – 18 kHz
Horizontal Coverage (-6 dB)
80º
Vertical Coverage
70º
Nominal Impedance
8 ohms
Transformer Taps 70 V
5 W-10 W-15 W
Transformer Taps 100 V
10 W-20 W-30 W
RMS Power Handling
100 W
Peak Power Handling
400 W
On-axis Sensitivity 1W/1 m
90 dB SPL
Maximum Peak SPL at 1 m
137 dB
Recommended Amplifier
INTEGRAL-A402 INTEGRAL-A404
Recommended Processor
INTEGRAL-M88 INTEGRAL-MA1604 INTEGRAL-MA1004
Connectivity
Audio Input Connector
Spring Terminals
Audio Output Connector
Spring Terminals
Construction
Enclosure Construction
High Impact ABS
Enclosure Geometry
Trapezoidal
Color
White
LF Driver
4G4
HF Driver
TWT-24
Dimensions
Enclosure Dimensions (H x W x D)
340 x 145 x 140 mm 13,4 x 5,7 x 5,5 in
Weight
Net Weight
2,6 kg ( 5,7 lb )
Shipping
Carton Dimensions (H x W x D)
455 x 330 x 170 mm 17,9 x 13,0 x 6,7 in
Shipping Weight
3,3 kg ( 7,3 lb )
