Specifications
Performance
Frequency Range (-10 dB)
60 Hz – 18 kHz
Horizontal Coverage (-6 dB)
90º
Vertical Coverage
90º
Nominal Impedance
8 ohms
Transformer Taps 70 V
2.5 W-5 W-7.5 W
Transformer Taps 100 V
5 W-10 W-15 W
RMS Power Handling
50 W
Peak Power Handling
200 W
On-axis Sensitivity 1W/1 m
90 dB SPL
Maximum Peak SPL at 1 m
137 dB
Recommended Amplifier
INTEGRAL-A402 INTEGRAL-A404
Recommended Processor
INTEGRAL-M88 INTEGRAL-MA1604 INTEGRAL-MA1004
Connectivity
Audio Input Connector
Spring Terminals
Audio Output Connector
Spring Terminals
Construction
Enclosure Construction
High Impact ABS
Enclosure Geometry
Trapezoidal
Color
White
LF Driver
4G
HF Driver
TWT-4
Dimensions
Enclosure Dimensions (H x W x D)
210 x 135 x 140 mm 8,3 x 5,3 x 5,5 in
Weight
Net Weight
1,6 kg ( 3,5 lb )
Shipping
Carton Dimensions (H x W x D)
325 x 330 x 170 mm 12,8 x 13,0 x 6,7 in
Shipping Weight
2,2 kg ( 4,9 lb )
