Specifications
Audio
Frequency Range (-10 dB)
60 Hz – 20 kHz
Nominal Impedance
8 ohms
Conical Coverage
95º
RMS Power Handling
40 W
Peak Power Handling
160 W
On-axis Sensitivity 1W/1 m
90 dB SPL
Maximum Peak SPL at 1 m
112 dB
Connectivity
Audio Input Connector
Spring Terminals
Audio Output Connector
Spring Terminals
Construction
Enclosure Geometry
Round
Color
White
Driver Size
6.5"
Dimensions
Cut Out Diameter
210 mm (8.3 in)
Enclosure Dimensions (H x W x D)
230 x 230 x 80 mm / 9.0" x 9.0" x 3.2"
Carton Dimensions (H x W x D)
270 x 250 x 390 mm / 10.6" x 9.8" x 15.4"
Weight
Net Weight
1.2 kg (2.6 lb)
Shipping Weight
1.4 kg (3.0 lb)
Compatibility
Recommended Amplifier
INTEGRAL-A402, INTEGRAL-A404, INTEGRAL-A1002, INTEGRAL-A1004, INTEGRAL-A1602, INTEGRAL-A1604, INTEGRAL-MA1004, INTEGRAL-MA1604
Recommended Processor
INTEGRAL-M88, INTEGRAL-MA1604, INTEGRAL-MA1004
