Specifications
Audio
Frequency Range (-10 dB)
60 Hz – 20 kHz
Nominal Impedance
8 ohms
Conical Coverage
95º
On-axis Sensitivity 1W/1m
90 dB SPL
Maximum Peak SPL at 1m
112 dB
Transformer Taps 70 V
Tap1, 2.5 W. Tap2, 5 W. Tap3 7.5 W.
Transformer Taps 100 V
Tap1, 5 W. Tap2, 10 W. Tap3 15 W.
Connectivity
Audio Input Connector
Spring Terminals
Audio Output Connector
Spring Terminals
Dimensions
Enclosure Geometry
Round
Cut Out Diameter
210 mm (8.3 in)
Dimensions (H x W x D)
230 x 230 x 80 mm (9.0" x 9.0" x 3.2")
Carton Dimensions (H x W x D)
270 x 250 x 390 mm (10.6" x 9.8" x 15.4")
Weight
Net Weight
1.4 kg (3.1 lb)
Shipping Weight
1.5 kg (3.3 lb)
Construction
Color
White
Compatibility
Recommended Amplifier
INTEGRAL-A402 INTEGRAL-A404 INTEGRAL-A1002 INTEGRAL-A1004 INTEGRAL-A1602 INTEGRAL-A1604 INTEGRAL-MA1004 INTEGRAL-MA1604
Recommended Processor
INTEGRAL-M88 INTEGRAL-MA1604 INTEGRAL-MA1004
