Specifications
Dimensions
Dimensions (HxWxD)
10.8" x 28.9" x 14.6"
Audio
Max SPL (at 1m)
134dB
Input Impedance
20k ohms
Input Sensitivity
6.2V (+18dBu)
Audio Signal Input Connector
1x female XLR
Audio Signal Loop Thru Connector
1x male XLR
Connectivity
Input Type
balanced
AC Output Connector
powerCON NAC3FCB
Construction
Construction
birch plywood, black ISO-flex paint finish
Shipping
Weight
71.7 pounds (35.2 kg)
General
Frequency Range (-10dB)
70Hz - 20kHz
Horizontal Coverage
90°
Vertical Coverage
splay dependent
LF Continuous
180W
LF Peak
360W
MF Continuous
180W
MF Peak
360W
HF Continuous
180W
HF Peak
360W
115V
-/3.0 A
230V
a:0:{}
LF Driver
10MI4
MF Driver
10MI4
Horn/waveguide
BPS-90AR
Rigging
captive rigging system
Drivers
HF Driver
M-75
