Specifications
Dimensions
Dimensions (HxWxD)
13.4" x 25.6" x 18.1"
Audio
Max SPL (at 1m)
132dB
Input Impedance
20k ohms
Input Sensitivity
6.2V (+18dBu)
Audio Signal Input Connector
1x female XLR
Audio Signal Loop Thru Connector
1x male XLR
Connectivity
Input Type
balanced
AC Output Connector
powerCON NAC3FCB
Construction
Construction
birch plywood, black ISO-flex paint finish
Shipping
Weight
51.8 pounds (23.5 kg)
General
Frequency Range (-10dB)
70Hz - 20kHz
Horizontal Coverage
60°
Vertical Coverage
20° up / 30° down
LF Continuous
180W
LF Peak
360W
MF Continuous
180W
MF Peak
360W
HF Continuous
180W
HF Peak
360W
115V
-/3.0 A
230V
a:0:{}
LF Driver
10MI4
MF Driver
10MI4
Horn/waveguide
BC-632
Rigging
captive rigging system
Drivers
HF Driver
M-60
