Specifications
Performance
Frequency Range (-10 dB)
63 Hz – 20 kHz
Horizontal Coverage (-6 dB)
90º
Vertical Coverage
90º
Nominal Impedance
100 ohms
RMS Power Handling
100 W
Peak Power Handling
400 W
On-axis Sensitivity 1W/1 m
96 dB SPL
Maximum Peak SPL at 1 m
126 dB
Recommended Amplifier
INTEGRAL-A1002 INTEGRAL-A1004
Audio
Line Transformer
70 V/100 V
Connectivity
Audio Input Connector
Spring Terminals
Audio Output Connector
Spring Terminals
Construction
Enclosure Construction
Polypropylene
Enclosure Geometry
Round
Color
White
LF Driver
12MX
HF Driver
M-34
Dimensions
Enclosure Dimensions (H x W x D)
19.7" x 19.9" x 11.4"
Weight
Net Weight
23.2 lbs
Shipping
Carton Dimensions (H x W x D)
13.4" x 22.2" x 22.2"
Shipping Weight
27.6 lbs
