Specifications
Dimensions
Depth
460 mm (18,1 in)
Dimensions (HxWxD)
30.5x18.3x18.1” (775x465x460mm)
Carton Dimensions (HxWxD)
34.3x21.7x20.9” (870x550x530mm)
Weight
Net Weight
72.8 lbs (33kg)
Shipping Weight
88lbs (40kg)
Audio
On-axis Sensitivity 1W/1 M
98 dB SPL
Maximum Peak SPL at 1 M
133 dB
Audio Input Connector
Covered Barrier Strip Terminals
Audio Output Connector
Covered Barrier Strip Terminals
Construction
Enclosure Construction
Birch Plywood
Finish
Fiberglass
Color
Black
Environmental
IP Rating
IP54
General
Frequency Range (-10 dB)
45 Hz – 125 Hz
Nominal Impedance
Passive: 4 ohms Biamp: 8 ohms
RMS Power Handling
800 W
Peak Power Handling
3200 W
Recommended Amplifier
PA-1500
Recommended Processor
DSP-226
Enclosure Geometry
Rectangular
Rigging
M10 Rigging Points
LF Driver
15SX
