Specifications
Audio
Analogue Audio Input
1x stereo RCA (L/R), 2x mono microphone
Analogue Audio Output
1x stereo RCA (L/R), 1x stereo headphone (mini jack with volume control)
Embedded Audio Support
input 2 channels, output 2 channels
Connectivity
Video Input
4x HDMI
Video Output
2x HDMI (1 is MV, 1 is PGM), HDMI 1 (PC) loop out
Down-converted Output
yes
Tally Output
1x D-sub 15pin, dual color
General
Video Standard
full HD and SD
Video Forma
1080p 50/59.94/60Hz, 1080i 50/59.94/60Hz, 720p 50/59.94/60Hz, 576i 50Hz, 480i 59.94Hz
Video Processing
HDMI YUV 4:4:4 10 bit, RGB 4:4:4
Mix HD and SD Source
yes
Computer Graphic Interface
4 via HDMI
Built-in Multi-view Monitoring Out
HDMI
A+V Switching
yes
USK
lumakey
Picutre in Picture
1
Effects
FTB, cut, wipe with border
Sync/reference in/out
built-in Genlock (internal)
Special Features
built-in video scaler for mixed resolution inputs
Power
Power
DC 12V, 29W
