Specifications
Dimensions
Dimensions (WxHxD)
16.5" x 28.4" x 16.5"
Audio
Frequency Response
50 - 20,000 Hz (-10dB), 56 - 19,000 Hz (-3dB)
Max SPL
130 dB
Connectivity
Signal Input
1x combo (XLR/jack 6.3 mm) mic/line, 1x combo (XLR/jack 6.3 mm) mic/inst
Signal Output
1x XLR male (CH1 link/mix out) selectable
Construction
Housing
polypropylene with internal frame
Pole Mount
D36 mm
Shipping
Weight
40.34 pounds (18.3 kg)
General
HF
1" exit, 1.4 v.c.
Type HF
compression driver
Horizontal Directivity
100° (85° up/120° down)
Vertical Directivity
85° (+ 25°/-60°)
Horn
asymmetrical horn
LF
15", 2" v.c.
Amp Technology
amp SMPS power supply dual range
Amp Class
class D
RMS Power
600 W
Peak Power
1200 W
Controller
DSP 56 bit
AD/DA Converter
24 bit/48 KHz
System Presets
rotary encoder (8 presets)
X-over Frequency
1800 Hz
Limiter
peak, RMS, thermal
Advanced DSP Functions
linear phase FIR filters
Rigging Points
2x M10 on top, 1x M10 on back
Angles Up
monitor use 45°
