dBTechnologies DVA KS20 Powered Subwoofer
dBTechnologies DVA KS20 Powered Subwoofer
SoundPro Item: 76327 | Part Number: DVA KS20
Usually ships in 5-7 business days
- Powerful and quiet amplification with Digipro G3 Class D amplifier
- High-quality 2 x 18" woofers
- 1800W RMS power, 3600W peak power
- Fast and accurate DSP configuration using delay, phase and crossover controls
- Handles and mounting points ensure fast and versatile setup
DVA KS20 is the perfect low-end complement for larger DVA K5 systems and can be used vertically in groundstacked configurations thanks to the DRK-20/10 pickpoints on top.
Featuring a double 18" woofer pairing in a bass reflex housing, the DVA KS20 is equipped with 2x Digipro G3 Power Amplifiers delivering 4000 W Peak. The system's internal design brings together the benefits of bass reflex and horn- loaded systems in a compact, sturdy housing covered with robust black laquer. The 56 Bit DSP manages limiters and delays for flawless system processing.
- Speaker typeactive bassreflex horn-loaded subwoofer
- Frequency response41-120Hz (-10dB)
- Max SPL138 dB
- Directivityomnidirectional
- LF2x18", 4" vc
- AmplifierDigipro® G3 Class D
- RMS power1800W
- Peak power3600W
- Coolingconvection
- Power supply1800W SMPS with auto range PSU
- ControllerDSP 56 bit
- AD/DA converter24bit / 48kHz
- System presetsX-Over, delay
- Limiterdual active multiband RMS, peak, thermal
- Crossover frequency LF-HF90, 120 Hz (selectable)
- Slope LF-HF24dB/Octave
- Input selection2x XLR balanced
- Output selection2x XLR balanced
- Power socket1x PowerCon in + 1x PowerCon out
- Controls
- 1x input sensitivity rotary switch
- 1x setup rotary encoder (delay up to 4.5 ms on-board)
- 1x polarity inversion switch
- 1x x-over frequency switch (90Hz, 120Hz)
- 1x output mode switch (link- x-over)
- Housingplywood
- Handles3 per side
- Rigging points2 pick points on top to fix DRK10/20 rigging frames
- Pole mount1 M20 on top
- Dimensions (WxHxD)43.31" x 22.83" x 28.53"
- Weight185.19 pounds (84 kg)
