dbTechnologies DVA S30N Subwoofers

dbTechnologies DVA S30N Subwoofers

SoundPro Item: 48961 | Part Number: DVA S30N

$4,899.00
$5,634.00 $4,899.00
Your Price Sold out
MSRP: $5,634.00 | MAP: $4,899.00

Usually ships in 5-7 business days

  • Active Bassreflex Horn-Loaded Subwoofer
  • 3000W RMS Digipro G2 Amp Technology
  • 141 Db Max SPL
  • Frequency Response [+/- 3 dB]: 30 - 120 Hz
  • LF: 2 X 18”, 4” V.C.
  • Weight: 83 Kg (182.98 Lbs.)
Log in or register for YOUR best price

DVA S30N subwoofer features a sophisticated hybrid design able to bring together the benefits of bass reflex and horn systems in a compact housing, engineered to render low frequencies with high sound pressure levels. The two baffle boards are arrayed in the form of a V and guide the central bass reflex channel‘s sound energy into the horn's port. This funneling action is smooth and uniform, greatly increasing its range.
The high-quality multiplex housing is covered in robust black textured lacquer and equipped with eight grips.

View full details

Specifications

Technical Data
Speaker Type: Active Bassreflex-Horn Subwoofer
Acoustical data
Frequency Response [+/- 3dB]: 30 - 120 Hz
Max SPL: 141 dBB
Directivity: Omnidirectional, Cardiod Option with DSP setup
LF: 2x18"
Voice Coil LF: 4"
Amplifier
Amp Technology: Digipro G2
Amp Class: Class D
Power Supply: 3 kW SMPS
LF Amp: 3000 W RMS
Cooling: Convection
Processor
Controller: DSP 56 bit
AD/DA Converter: DSP 24 bit/48 kHz
System Presets: X-Over,Delay
Phase: 0, 180 °
Limiter: RMS, Peak, Thermal
Delay Option: 0-4.5 ms internal
Crossover Frequency LF-MF: 75-120Hz | steps of 5Hz
LF-Xover out slope: 24 dB/Octave
Mechanics
Housing: Multiplex plywood
Housing Design: Rectangular
Handles: 4x Per Side
Accessory: Dolly, Wheels 100mm and Dust Cover, Rain Cover
Rigging Points: 2xPick Points on top to fix, DRK10/20 rigging Frames
Dimensions (W x H x D)
1100 mm (44 in) x 580 mm (23.2 in) x 720 mm (28.8 in)
Weight: 83 kg (182.98 lbs)
