Specifications
Audio
Directional Pattern
Wide cardioid
Principle of Operation
Pressure gradient
Cartridge Type
Pre-polarized condenser
Frequency Response
20 Hz - 20 kHz
Effective Frequency Range (±2 dB at 30 cm)
40 Hz to 18 kHz
Sensitivity (nominal, ±2 dB at 1 kHz)
12 mV/Pa
Equivalent Noise Level (A-weighted)
Typ. 18 dB(A) re. 20 µPa (max. 20 dB(A))
Distortion (THD < 1%)
147 dB SPL, 150 dB SPL peak
Dynamic Range
Typ. 132 dB
Max. SPL (THD 10%)
153 dB SPL peak
Maximum Output Voltage (RMS)
8.7 V (21 dBu)
Rated Output Impedance
60 Ω
Common Mode Rejection Ratio (CMRR)
> 60 dB
Output Balance Principle
Impedance balancing with Active Drive
Polarity
+V at pin 2 for positive sound pressure
Connectivity
Connector
XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
Cable Drive Capability
100 m (328 ft)
Power
Power Supply
P48 (Phantom Power)
Current Consumption
0.7 mA
Dimensions
Microphone Diameter
19 mm (0.75 in)
Capsule Diameter
17 mm (0.67 in)
Microphone Length
94 mm (3.7 in)
Weight
Product Weight
83 g (2.9 oz)
Environmental
Temperature Range
-40°C to 45°C (-40°F to 113°F)
Relative Humidity
Up to 90%
Identifiers
Color
Black
