- Transducer TypeCondenser
- Polar PatternCardioid
- Frequency Response20 Hz - 20 kHz
- Rated Output Impedance100 ohms
- Sensitivity, Nominal ±2 dB at 1 kHz10 mV/Pa; -40 dB re. 1 V/Pa
- Equivalent Noise Level, A-Weightedtyp. 20 dB(A) re. 20 µPa (max. 23 dB(A))
- Equivalent Noise Level, ITU-R BS.468-4typ. 33 dB (max. 36 dB)
- Distortion, THD < 1%134 dB SPL RMS, 137 dB SPL peak
- Dynamic Rangetyp. 117 dB
- Max. SPL, THD 10%146 dB SPL peak
- Cable Drive Capability100 m (328 ft)
- Output Balance PrincipleImpedance balancing with Active Drive
- CMRR> 50 dB
- Power Supply (for full performance)P48 (Phantom Power)
- Current consumption2.8 mA
- ConnectorXLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
- Colormatte black
- Weight2.3 oz
- Dimensions0.75" diameter x 3.6" length
- Max. Output Voltage, RMS4.5 V
- Sensitivity Selection Tolerance (at 1kHz)±1.5 dB
