Specifications
Audio
Directional Pattern
Supercardioid
Principle Of Operation
Pressure gradient
Frequency Response
20 Hz - 20 kHz
Effective Frequency Range
40 Hz - 16 kHz with 3 dB soft boost at 12 kHz
Sensitivity
5 mV/Pa; -46 dB re. 1 V/Pa
Sensitivity With Wireless Adapter
2 mV/Pa; -54 dB re. 1 V/Pa
Equivalent Noise Level
Typ. 19 dB(A) re. 20 µPa (max. 21 dB(A))
Dynamic Range
Typ. 120 dB
THD < 0.5%
147 dB SPL RMS, 150 dB SPL peak
THD < 1%
151 dB SPL RMS, 154 dB SPL peak
Max SPL (THD 10%)
160 dB SPL peak
Maximum Output Voltage RMS
8 V
Electrical
Power Supply
P48 (Phantom Power)
Current Consumption
Max 2.0 mA
Rated Output Impedance
100 Ω
Minimum Load Impedance
1 kΩ
Cable Drive Capability
100 m (328 ft)
Output Balance Principle
Impedance balancing with Active Drive
Common Mode Rejection Ratio
> 50 dB at 1 kHz
Connectivity
Connector
XLR-3M (Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase)
Polarity
+V at pin 2 for positive sound pressure
Construction
Cartridge Type
Pre-polarized condenser
Color
Matte black
Microphone Diameter
52 mm (2.05 in)
Capsule Diameter
19 mm (0.75 in)
Microphone Length
205 mm (8.1 in)
Weight
309 g (10.9 oz)
Environmental
Temperature Range
-40°C to 45°C (-40°F to 113°F)
Relative Humidity
Up to 90%
