DPA Microphones 4060 Omni Miniature Lavalier Mic | TA4F Mini-XLR | Beige

DPA Microphones 4060 Omni Miniature Lavalier Mic | TA4F Mini-XLR | Beige

SoundPro Item: 150872 | Part Number: 4060-OP-C-F10

$690.00
$690.00 $690.00
Your Price Sold out
MSRP: $690.00 | MAP: $690.00

Usually ships in 5-7 business days

  • IP58 Capsule Protection Ensures Reliable Operation In Humid And Dusty Environments
  • Modular Adapter System Provides Direct Compatibility With Major Wireless Platforms
  • Pre-Polarized Condenser Cartridge Delivers Flat Response Without External Bias Supply
  • Miniature Profile Allows Invisible Mounting For On-Camera And Theatrical Use
  • Extended Cable Drive Capability Supports Long Runs In Fixed Installation Applications
Log in or register for YOUR best price

The DPA 4060 series brings measurement-grade capsule technology to professional lavalier applications where remote placement and environmental exposure demand both sonic accuracy and physical resilience. Originally developed from hearing aid and precision instrumentation platforms, this omnidirectional miniature microphone delivers consistent frequency response across the full 20 Hz to 20 kHz spectrum while maintaining a 23 dB(A) noise floor that preserves intelligibility in broadcast interviews, theatrical performances, and documentary fieldwork.

Engineered for integration with professional wireless transmitters through DPA's modular adapter system, the 4060 handles maximum sound pressure levels up to 134 dB peak before clipping—making it suitable for close-mic applications on high-output sources or unpredictable live event scenarios. The IP58-rated capsule withstands moisture and particulate exposure that would compromise conventional lavaliers, while the 5.4 mm diameter profile enables discreet mounting on talent without visual distraction. Theater sound designers, ENG crews, and house of worship engineers rely on this platform when concealment, durability, and tonal uniformity across multiple units are non-negotiable.

Unlike larger lavalier designs that color off-axis response or exhibit handling noise, the 4060's pressure-operated condenser cartridge maintains omnidirectional polar characteristics and mechanical isolation from cable movement. With sensitivity selection tolerance held to ±1.5 dB at 1 kHz, multi-mic installations achieve level matching without extensive gain adjustments. The included 1.8 m cable supports flexible routing, and compatibility with up to 300 m cable runs when paired with the DAD9001 XLR adapter extends the microphone's utility into fixed installation and remote broadcast environments where long signal paths are required.

Downloads

View full details

Specifications

Certifications
Capsule IP Rating
IP58
Audio
Directional Pattern
Omnidirectional
Principle Of Operation
Pressure
Cartridge Type
Pre-polarized Condenser
Frequency Response
20 Hz - 20 kHz
Effective Frequency Range ±2 dB
Soft boost grid: 20 Hz - 20 kHz, 3 dB soft boost at 8 - 20 kHz. High boost grid: 20 Hz - 20 kHz, 10 dB boost at 12 kHz
Sensitivity, Nominal, ±3 dB At 1 kHz
20 mV/Pa; -34 dB re. 1 V/Pa
Equivalent Noise Level, A-Weighted
Typ. 23 dB(A) re. 20 µPa (max. 26 dB(A))
Equivalent Noise Level, ITU-R BS.468-4
Typ. 35 dB (max. 38 dB)
Distortion, THD < 0.5%
128 dB SPL RMS, 131 dB SPL peak
Distortion, THD < 1%
129 dB SPL RMS, 132 dB SPL peak
Dynamic Range
Typ. 109 dB
Max. SPL, THD 10%
134 dB SPL peak
Rated Output Impedance
30 - 40 Ω
Sensitivity Selection Tolerance (At 1 kHz)
±1.5 dB
Polarity
Positively increasing sound pressure produces positive going voltage on MicroLock pin
Connectivity
Connector
TA4F Mini-XLR
Cable Drive Capability
Up to 300 m (984 ft) with DAD9001 XLR Adapter
Power
Power Supply (For Full Performance)
For wireless systems Min. 5 V - max. 10 V through DPA adapter. With DAD9001: P48 (Phantom Power). Will work from 12 V
Current Consumption
Typ. 1.5 mA (microphone). 3.5 mA with DAD9001 XLR Adapter
Construction
Color
Beige
Weight
7.5 g (0.26 oz) incl. Cable and MicroLock connector
Microphone Diameter
5.4 mm (0.21 in)
Microphone Length
12.7 mm (0.5 in)
Cable Length
1.8 m (5.9 ft)
Environmental
Temperature Range
-40°C to 45°C (-40°F to 113°F)
Relative Humidity (RH)
Up to 90%
