DPA Microphones 4488 CORE+ Directional Headset Mic | TA4F Mini-XLR | Beige

DPA Microphones 4488 CORE+ Directional Headset Mic | TA4F Mini-XLR | Beige

SoundPro Item: 150949 | Part Number: 4488-DP-R-F10

$1,160.00
$1,160.00 $1,160.00
Your Price Sold out
MSRP: $1,160.00 | MAP: $1,160.00

Usually ships in 5-7 business days

  • One-Size-Fits-All Frame With Adjustable 3-Point Grip Accommodates Diverse Head Sizes And Shapes
  • Flexible Boom And Frame Adjustment Enables Precise Capsule Placement For Consistent Source Distance
  • 90-Degree Rotatable Cable Guide Routes Wiring Discreetly Behind The Ear And Out Of Sightlines
  • Non-Reflective PVD Surface Treatment On Frame And Capsule Eliminates Stage Light Reflections
  • IP58 Capsule Rating Protects Against Moisture And Environmental Exposure During Live Use
  • Compatible With Wireless Systems Operating Between 5 V And 10 V Through DPA Adapters
Log in or register for YOUR best price

The 4488 CORE+ Directional Headset Microphone integrates DPA's 5 mm capsule technology with CORE+ by DPA processing in a Red Dot award-winning dual-ear headset platform engineered for theatre, broadcast, house of worship, and conferencing professionals. The cardioid polar pattern efficiently suppresses distant sound sources and provides exceptional off-axis rejection, making it the right choice for live performance environments where background noise and feedback control are critical.

The bass response is optimized for linearity at 2-3 cm placement distance, producing intentional low-frequency roll-off at greater distances that enhances background noise rejection and feedback margin. The one-size-fits-all frame accommodates diverse head sizes through a comfortable 3-point grip system that secures above, below, and behind the ear. Boom length, frame size, and capsule placement adjust easily for consistent positioning, while the 90° cable guide keeps wiring out of sight during performance.

The non-reflective PVD surface treatment on the frame, boom, and capsule eliminates visual distraction under stage lighting. IP58 capsule protection withstands moisture and environmental exposure typical of touring and installed systems. The design supports cable runs up to 300 m when paired with the DAD9001 XLR adapter, providing integrators with flexible routing options in large venues.

Downloads

View full details

Specifications

Certifications
Capsule IP Rating
IP58
Audio
Directional Pattern
Cardioid
Principle Of Operation
Pressure gradient
Cartridge Type
Pre-polarized condenser
Frequency Response
20 Hz - 20 kHz
Effective Frequency Range
100 Hz - 20 kHz (4 - 6 dB soft boost at 15 kHz), Near field 2-3 cm
Sensitivity
6 mV/Pa; -44 dB re. 1 V/Pa
Equivalent Noise Level A-Weighted
Typ. 26 dB(A) re. 20 µPa (max. 28 dB(A))
Equivalent Noise Level ITU-R BS.468-4
Typ. 38 dB (max. 40 dB)
Distortion THD < 0.5%
137 dB SPL RMS, 140 dB SPL peak
Distortion THD < 1%
139 dB SPL RMS, 142 dB SPL peak
Dynamic Range
Typ. 116 dB
Max. SPL THD 10%
147 dB SPL peak
Rated Output Impedance
30 - 40 Ω
Connectivity
Connector
TA4F Mini-XLR
Cable Drive Capability
Up to 300 m (984 ft) with DAD9001 XLR Adapter
Power
Power Supply
Min. 5 V - max. 10 V through DPA adapter (wireless systems); P48 Phantom Power with DAD9001 (will work from 12 V)
Current Consumption
Typ. 1.5 mA (microphone); 3.5 mA with DAD9001 XLR Adapter
Construction
Microphone Diameter
5.4 mm (0.21 in)
Cable Length
1.3 m (4.3 ft)
Cable Diameter
1.6 mm (0.06 in)
Color
Beige
Weight
22 g (0.4 oz) incl. cable and MicroLock connector
Polarity
Positively increasing sound pressure produces positive going voltage on MicroLock pin
Environmental
Temperature Range
-40°C to 45°C (-40°F to 113°F)
Relative Humidity
Up to 90%
