Specifications
Cable Type
Professional AES/EBU Digital Cable
Model
DMX605
Conductor Size
4 × 0.34 mm²
Conductor Material
OFC (Oxygen Free Copper)
Conductor Drains
OFC tinned; 30 × 0.12 mm
Conductor Insulation
LPE; white + blue; 1.2 mm
Nominal Impedance
110 Ω
Conductor Resistance
<80 Ω/km
Shield Resistance
300 Ω/km
Capacitance Inner Conductor
64 pF/m
Shield Type
Tinned copper braid (96 × 0.12 mm) with aluminum foil
Jacket Type
Flexible PVC
Temperature Range
−20°C to +70°C
