Specifications
Dimensions
Dimensions (LxWxH)
18.54" x 13.11" x 31.69"
Electrical
Electrical / Thermal
AC 100-240V 50/60Hz, BTU/hr (+/- 10%) 4456.87, 14°F to 113°F (-10°C to 45°C)
Max. Power Consumption
1300W
Optics
Zoom Range
11° - 55°
Beam Angle
6.1° - 43.1°
Field Angle
5.1° - 64.9°
Connectivity
Total Lumen Fixture Output
51,000
Construction
Color
SpectraColor CMY + RGB color mixing array, 6 dichroic colors including high CRI filter and UV, Linear CTO color correction
Shipping
Weight
94.7 pounds
General
Source
950W 6500K bright white LED engine, 30,000 hour average LED life
CRI
72+ (85+ with HCRI Filter)
Effects
Motorized zoom (fresnel), 4 full blackout framing blades, 360° framing index - continuous framing rotation, 2 bidirectional animation wheels, 2 variable frost filters (medium and heavy), High speed iris, Focus edge control, Variable 16-bit dimming curve modes, High-speed electronic shutter and strobe, Adjustable LED refresh rate frequency
Pan Angle
540° / 630°
Tilt Angle
250°
Control / Connections
2 DMX channel modes (35 / 59), 16-bit pan, tilt and dimming control, DMX, RDM, Art-NET, and sACN protocol support, 6 button touch control panel, Full color 180° reversible LCD menu display, Hibernation mode (power save), Locking 5pin XLR DMX, RJ45 Ethernet, and power, With wired digital communication network
