Elation CHORUS LINE 16 Pixel Bar Wash Fixture
Elation CHORUS LINE 16 Pixel Bar Wash Fixture
SoundPro Item: 75057 | Part Number: CHORUS LINE 16
Usually ships in 5-7 business days
- 16 Pixel Bar Wash Luminaire with 40W 4-in-1 RGBW LEDs
- Motorized 4° to 40° Zoom and 220° Tilt Movement
- RGBW Color Mixing and Full Pixel Control
- 2,700K - 7,000K Linear Color Temperature Range
- 64 Color Presets and 14 Unique Color Macros
- Electronic Strobe, 16-bit Variable Dimming Curve Modes
- Adjustable LED Refresh Rate Frequency
- Adjustable LED Gamma Brightness
- Flicker Free Operation for TV and FILM
- DMX, RDM, Kling-Net, Art-Net Protocol Support
CHORUS LINE 16 is a 16 pixel bar wash luminaire featuring 40W 4-in-1 RGBW LEDs, motorized 4° to 40° zoom and 220° tilt, full pixel control, adjustable linear color temperature (2,700K - 7,000K), 64 color presets and 14 unique color macros, electronic strobe, 16-bit dimming and selectable dimming curve modes, adjustable LED refresh rate frequency and gamma brightness for flicker free operation for TV and FILM, DMX, RDM (Remote Device Management) Kling-NET, and Art-Net protocol support, DMX, etherCON, and power in/out connections, (4) button LCD control display panel, dual quick-lock rigging, and a multi-voltage universal auto switching power supply (100-240v).
- SOURCE
- (16) 40W 4-in-1 RGBW LEDs
- 50,000 Hour Average LED Life*
- *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.
- PHOTOMETRIC DATA
- 5,700+ Total Lumens
- 20,478 LUX 1903 FC @16.4 ft (5m) (Full ON (4° Min Zoom)
- 570 LUX 53 FC @16.4 ft (5m) (Full ON (37° Max Zoom)
- Zoom Range 4° - 40°
- Beam Angle 4.6° - 37.8°
- Field Angle 7.8° - 54.4°
- EFFECTS
- Motorized Zoom and 220° Tilt Movement
- RGBW Color Mixing and Full Pixel Control
- 2,700K - 7,000K Linear Color Temperature Range
- 64 Color Presets and 14 Unique Color Macros
- Electronic Strobe, 16-bit Variable Dimming Curve Modes
- COLORRGBW
- CONTROL / CONNECTIONS
- 3 DMX Channel Modes (78 total channels)
- DMX, RDM, Kling-Net, and Art-Net Protocol Support
- Adjustable LED Refresh Rate (900-25,000 Hz)
- Adjustable LED Gamma Brightness (2.0, 2.2, 2.4, 2.8)
- 4 Button Touch Control Panel
- 180° Reversible LCD Menu Display
- 8 / 16-Bit Resolution Zoom and Tilt Movement
- 5pin DMX In/Out
- RJ45 Ethernet In/Out
- Locking Power Cable In/Out
- With Wired Digital Communication Network
- SIZE / WEIGHT
- Length: 42.05" 1068mm)
- Width: 7.44" (189mm)
- Vertical Height: 11.46" (291mm)
- Weight: 47.0 lbs (21.3 kg)
- ELECTRICAL / THERMAL
- AC 100-240V - 50/60Hz
- 739W Max Power Consumption
- 5°F to 113°F (-15°C to 45°C)
- BTU/hr (+/- 10%) 2519.99
- APPROVALS / RATINGSCE | cETLus | IP30
