Elation DMX153 10-Port DMX Splitter Rackmount

Elation DMX153 10-Port DMX Splitter Rackmount

SoundPro Item: 144092 | Part Number: DMX153

$476.00
$560.00 $476.00
Your Price Sold out
MSRP: $560.00 | MAP: $476.00

Usually ships in 5-7 business days

  • Opto-Isolated Outputs Eliminate Ground Loop Hum In Multi-Fixture Rigs
  • Independent Toggle-Switch A/B Routing On Each Of 10 Output Ports
  • LED Feedback Displays Input Status, Output Activity, And Port Selection
  • Compact 1U Rackmount Housing Fits Standard Touring And Install Racks
  • Rugged Powder-Coated Metal Chassis Withstands Repeated Transport
Log in or register for YOUR best price

The Elation DMX153 is a professional-grade rackmount DMX splitter engineered for touring productions and permanent installations requiring multi-destination signal distribution without RDM capability. Each of the 10 output ports features independent toggle-switch routing to either the A (5pin) or B (3pin) input, eliminating the need for external patch cables or splitter chains and reducing setup time on location.

Opto-isolation on all outputs protects against ground loop hum and signal reflections common in large rigs where fixtures are daisy-chained or powered from separate branches. The rugged metal chassis, powder-coated industrial finish, and compact 1U rackmount form factor make this unit suitable for touring cases, mobile carts, and fixed system racks. LED indicators on every port confirm input presence, output activity, and active input selection, helping technicians verify signal flow during show setup and troubleshooting.

View full details

Specifications

Certifications
Approvals|cETLus, CE, UKCA, IP20
Dimensions
Length|6.10"
Width|19.0"
Height|1.7"
Weight
Product Weight|3.31 lbs
Electrical
Voltage|100-240 V, 50/60 Hz
Connectivity
DMX Input A|5pin XLR
DMX Input B|3pin XLR
5pin XLR Outputs|5 Opto-Isolated
3pin XLR Outputs|5 Opto-Isolated
Power In|Locking Connector
Included Items
Power Cable|1.5m Locking (EU or US)
Identifiers
UPC|810008263914
