Specifications
Dimensions
Dimensions (HxWxD)
471x576x825 mm (19x23x32")
Dimensions (HxWxD) Without Casters
19x23x27" (471x576x692 mm)
Weight
Net Weight
91.9 lbs (41.7 kg)
Shipping Weight
103.2 lbs (46.8 kg)
Electrical
Power Consumption
100 - 240 V~, 50 - 60 Hz, 1.6 - 0.8 A³
Audio
Power Rating
1800 W
Connectivity
Connectors
(2) XLR/TRS Combo Jack and (2) XLR link Output
Construction
Enclosure
18 mm, 13-ply birch plywood with EVCoat
Grille
16AWG steel with powdercoat
General
Frequency Response (-3 dB)
37 Hz - 150 Hz¹
Frequency Range (-10 dB)
32 Hz - 180 Hz¹
Maximum SPL
134 dB peak²
LF Transducer
DVX3159A 380 mm (15 in)
Low Pass Frequency
Adjustable 80 Hz, 100 Hz, 120 Hz, 150 Hz
Notes
¹ Half space measurement using the music DSP preset and 150 Hz low pass., ² Maximum SPL is measured at 1 m using broadband pink noise at maximum amplifier output., ³ Current rating is 1/8 power.
