Specifications
Dimensions
Dimensions (WxHxD)
345x597x347mm (13.58x23.5x13.66")
Electrical
Battery Capacity
86.4 Wh
Battery at Max output6
6+ hours of run optimize6+ hours of run time
Battery at Moderate output7
12+ hours of run time
Audio
SPL max1
126 dB
Bluetooth Audio Streaming and True Wireless stereo4
YES
Crossover Frequency
2000 Hz
Connectivity
Connectors
2x XLR/TRS combo jack 1x charge port 1x XLR output 1x 12 V DC power output 1x 3.5mm stereo 1x TRS footswitch
USB Charging
1.5 A max, device-dependent
Construction
Material
Enclosure: polypropylene
Grille
Steel with powder coat
Colors
Black
Shipping
Weight
14.16 kg (31.22 lbs)
General
Application
Pole-mounted / monitor / kick-back
Transducers
12” woofer, ferrite magnet, 1” compression driver, neodymium magnet, ferrofluid cooled
Power Rating (peak)
400W
Coverage (HxV)
100° x 60°
Frequency Range (-10 dB)2 / Response (-3 dB)3
45 Hz – 20 kHz / 55 Hz – 20 kHz
Digital Signal Processing
QuickSmartDSP features best-in-class processing powered by Dynacord. Easy setup via seven-band GEQ for main EQ, user-programmable presets, visual monitoring of limiter status, input level control and meters, digital effect control, and master volume control to optimize gain structure, all via LCD or the free QuickSmart Mobile app.
Remote Control and Monitoring
EV QuickSmart Mobile application: quickly and wirelessly configure, control and monitor up to six EVERSE 12 systems simultaneously, and receive immediate notification during critical performance conditions.
Power consumption5
100 - 240V~, 50 - 60 Hz, 1.2 - 0.6 A
Kick-back / Monitor Angles
25° / 55°
