• Electro-Voice EVF-1151S 15 Front-Loaded Subwoofer
1 1

Electro-Voice EVF-1151S 15-Inch Passive Subwoofer | Color: White

Electro-Voice EVF-1151S 15-Inch Passive Subwoofer | Color: White

SoundPro Item: 69704 | Part Number: F.01U.272.551

$2,583.00
$2,583.00 $2,583.00
Your Price Sold out
MSRP: $2,583.00 | MAP: $2,583.00

Usually ships in 5-7 business days

  • Enhanced bass for installations
  • Low-distortion EVS15SB woofer
  • 99 dB sensitivity, 131 dB maximum SPL
  • Power: 400W continuous, 1600W peak
  • Trapezoidal 13-ply birch enclosure
  • EVCoat, PI, or fiberglass (FG) finish
  • M10 threaded suspension points (22)
  • Available in black (pictured) and white (not pictured)
Log in or register for YOUR best price

EVF-1151S single 15" woofer more bass system is design to work as a low frequency reinforcement unit for EVF Series products, with equal footprint as the full range models, allows for perfect clustering in vertical and horizontal groupings.

View full details

Specifications

Dimensions
Height
30.26" (768.6mm)
Width
18.5" (470mm)
Depth
18.39" (467mm)
Dimensions (HxWxD)
30.26x18.5x18.4" (768.6x470x467mm)
Weight
Weight Net
62.61lbs (28.4kg)
Net Weight
62.6 lbs (28.4 kg)
Electrical
Minimum Impedance
Ω
Nominal Impedance (Passive)
Passive: 4 , Biamp: 8 Ω
Audio
Speaker Type
Subwoofer
Max. SPL/1m (calc)²
131dB
Sensitivity 1 W/1 M
99dB
Connectivity
Input Connections
Euroblock; PI and FG versions include dual gland nut input panel cover
Construction
Enclosure Material
13-ply weather-resistant birch
Grille
Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind
General
Frequency Range (-10 dB)
46–124 HzkHz
Suspension
22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)
Weatherized
No
HF Transducer
-
Frequency Response (-3 dB)¹
67–95 HzHz
Coverage (Nominal -6 dB) H
360°
LF Transducer
15" EVS15SB driver
System Power Handling (Continuous/Program/Peak)
400 , 800 , 1600 Watts
Recommended High-Pass Frequency
35Hz
Available Coverage Patterns (Nominal -6 dB) HxV
Omnidirectional in normal operating range°
Environmental Specs
Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55
Internal Passive Crossover Frequency
Hz
Internal Passive Low-Pass Filter
100 (12 dB per octave)
Coverage (Nominal -6 dB)
Omnidirectional in normal operating range
Passive Power Handling
1600W peak
