- Frequency Range (-10 dB) 28–650 HzkHz
- Suspension 28 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)
- Weatherized No
- Minimum Impedance Passive: N/A, Biamp: 6 Ω
- Nominal Impedance (Passive) Passive: N/A, Biamp: 8 Ω
- HF Transducer -
- Speaker Type Subwoofer
- Frequency Response (-3 dB)¹ 35–100 HzHz
- Max. SPL/1m (calc)² 131dB
- Coverage (Nominal -6 dB) H 360°
- LF Transducer 18" EVS18SB driver
- System Power Handling (Continuous/Program/Peak) 400 , 800 , 1600 Watts
- Enclosure Material 13-ply weather-resistant birch
- Grille Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind
- Sensitivity 1 W/1 m 99dB
- Height 30.26" (768.6mm)
- Width 26.6" (675.6mm)
- Recommended High-Pass Frequency 33Hz
- Depth 28.6" (726.4mm)
- Weight Net 101.19lbs (45.9kg)
- Available Coverage Patterns (Nominal -6 dB) HxV Omnidirectional in normal operating range°
- Environmental Specs Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55
- Nominal Impedance Passive: N/A, Bi-amp: 8Ω (Biamp)
- Internal Passive Crossover Frequency Hz
- Coverage (Nominal -6 dB) Omnidirectional in normal operating range
- Passive Power Handling 1600W peak
- Net Weight101.2 lbs (45.9 kg)
- Dimensions (HxWxD)30.26x26.6x28.6" (768.6x675.6x726.4 mm)
- Input ConnectionsEuroblock; PI and FG versions include dual gland nut input panel cover
