Electro-Voice EVU-1082/95 8-Inch Passive Install Speaker | Color: White
Electro-Voice EVU-1082/95 8-Inch Passive Install Speaker | Color: White
SoundPro Item: 45651 | Part Number: EVU-1082/95-WHT
In stock and ready to ship
- Sonically matched to all EV-Innovation lines
- Sophisticated 18-dB-octave passive crossover/EQ networks
- Asymmetrical enclosure for ideal under-balcony and stage-lip aiming
- Optional Neutrik Speakon(R) connector panel
- One 1.3"(33mm) diaphragm I compression driver
- U-bracket included
- Optional 70V and 100V operation
- OmniMount(R)-compatible rear mounting points
- Available in black or white (interior use)
- Ultracompact 10x16" enclosure
- 90x50 degree rotatable waveguide
- Ultra-high power handling for size: 175W continuous
- 123 dB Max SPL
- Asymmetrical trapezoidal enclosure design
- Compatible with OmniMount
Blend your sound into your surroundings with the EVU-1082/95 from Electro-Voice. This compact, two-way loudspeaker system is perfect when you need to fit high-quality sound reinforcement into a small space. The enclosure’s asymmetric angles let you mount the speaker into tight clearances while providing optimal coverage patterns.
The EVU-1082/95 incorporates the ICT-1-8, a high-output 1.3” diaphragm titanium compression driver coupled to a Constant Directivity™ 90° x 50° rotatable waveguide. The ICT-8-8 woofer is FEA-optimized, providing high sensitivity while achieving pristine speech intelligibility. The crossover design uses 18-dB-per-octave slopes with equalization for a smooth vocal response, linear off-axis response, and a protection circuit for long-term reliability.
- Frequency Range (-10 dB) 65 - 20000kHz (Half Space)
- Suspension (6) M8 threaded points
- Weatherized No
- Minimum Impedance 6Ω
- HF Transducer One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver
- Speaker Type Full-Range, Two-Way
- Frequency Response (-3 dB)¹ 110 - 16000Hz (Half Space)
- Max. SPL/1m (calc)² 123dB
- Coverage (Nominal -6 dB) H 90°
- LF Transducer One 8-inch (203 mm) ICT-8-8 woofer
- Coverage (Nominal -6 dB) V 50°
- Power Rating 700W
- System Power Handling (Continuous/Program/Peak) 175//700Watts (EIA RS-426A (eight hours))
- Connector Type 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)
- Enclosure Material 9-ply hardwood plywood
- Grille 18-gauge steel with cloth behind
- Available Color Black or white
- Height 9.72" (247mm)
- Width 16.1" (409mm)
- Recommended High-Pass Frequency 90Hz
- Depth9.33" (237mm)
- Weight Net16.31lbs (7.4kg)
- Shipping Weight22.71lbs (10.3kg)
- Nominal Impedance8Ω
- FinishTextured paint
- Waveguide6x6", rotatable
- Axial Sensitivity (SPL, 1W @ 1 m)95dB
- Passive Power Handling700W peak
