Electro-Voice EVU-2062/95 Dual 6.5-Inch Passive Install Speaker | Color: White
Electro-Voice EVU-2062/95 Dual 6.5-Inch Passive Install Speaker | Color: White
SoundPro Item: 45391 | Part Number: EVU-2062/95-WHT
In stock and ready to ship
- Sonically matched to all EV-Innovation lines
- Sophisticated 18-dB-octave passive crossover/EQ networks
- Asymmetrical enclosure for ideal under-balcony and stage-lip aiming
- Optional Neutrik Speakon(R) connector panel
- One 1.3" (33 mm) diaphragm compression driver
- U-bracket included
- Optional 70V and 100V operation
- OmniMount(R)-compatible rear mounting points
- Available in black or white (interior use)
- Ultracompact 8x21" enclosure
- 90º x 50º rotatable waveguide
- Ultra-high power handling for size: 300W continuous
- 125 dB Max SPL
- Asymmetrical trapezoidal enclosure design
- Compatible with OmniMount
Blend your sound into your surroundings with the EVU-2062/95 from Electro-Voice. This compact, two-way passive install speaker system is perfect when you need to fit high-quality sound reinforcement into a small space. The enclosure’s asymmetric angles let you mount the speaker into tight clearances while providing optimal coverage patterns.
The EVU-2062/95 incorporates the ICT-1-8, a high-output 1.3” diaphragm titanium compression driver coupled to a Constant Directivity™ 90° x 50° rotatable waveguide. The ICT-6.5-16 woofer is FEA-optimized, providing high sensitivity while achieving pristine speech intelligibility. The crossover design uses 18-dB-per-octave slopes with equalization for a smooth vocal response, linear off-axis response, and a protection circuit for long-term reliability.
- Frequency Range (-10 dB) 70 - 20000kHz (Half Space)
- Suspension Six M8 threaded points
- Weatherized No
- Minimum Impedance 6Ω
- HF Transducer One 1.3" (33 mm) diaphragm ICT-1-8 compression driver
- Speaker Type Full-Range, Two-Way
- Frequency Response (-3 dB)¹ 100 - 16000Hz (Half Space)
- Max. SPL/1m (calc)² 125dB
- Coverage (Nominal -6 dB) H 90°
- LF Transducer Two 6.5"(165mm) ICT-6.5-8 woofers
- Coverage (Nominal -6 dB) V 50°
- Power Rating 1200W
- System Power Handling (Continuous/Program/Peak) 300//1200Watts (EIA RS-426A (eight hours))
- Connector Type 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)
- Enclosure Material 9-ply hardwood plywood
- Grille 18-gauge steel with cloth behind
- Available Color Black or white
- Height 8.23" (209mm)
- Width 20.98" (533mm)
- Recommended High-Pass Frequency 90Hz
- Depth 8.15" (207mm)
- Weight Net 24.91lbs (11.3kg)
- Shipping Weight 31.31lbs (14.2kg)
- Nominal Impedance 8Ω
- Finish Textured paint
- Waveguide 6 in. x 6 in., rotatable
- Axial Sensitivity (SPL, 1W @ 1 m) 94dB (1W/1M)
- Passive Power Handling 1400W peak
