Specifications
Dimensions
Height
9.72" (247mm)
Width
24.21" (615mm)
Depth
9.33" (237mm)
Weight
Weight Net
28.22lbs (12.8kg)
Shipping Weight
35.27lbs (16kg)
Electrical
Minimum Impedance
6Ω
Audio
Speaker Type
Full-Range, Two-Way
Max. SPL/1m (calc)²
126dB
Power Rating
1400W
Sensitivity 1W/1 M
95dB
Axial Sensitivity (SPL, 1W @ 1 m)
95dB
Connectivity
Connector Type
4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)
Construction
Enclosure Material
9-ply hardwood plywood
Grille
18-gauge steel with cloth behind
Available Color
Black or white
Finish
Textured paint
General
Frequency Range (-10 dB)
60 - 20000kHz (Half-space)
Suspension
Six M8 threaded points
Weatherized
No
HF Transducer
One 1.3" (33 mm) diaphragm ICT-1-8 compression driver
Frequency Response (-3 dB)¹
100 - 16000Hz (Half-space)
Coverage (Nominal -6 dB) H
90°
Coverage (Nominal -6 dB) V
50°
LF Transducer
Two 8" (203 mm) ICT-8-8 woofers
System Power Handling (Continuous/Program/Peak)
350//1400W (EIA RS-426A (eight hours)
Recommended High-Pass Frequency
90Hz
Nominal Impedance
8Ω
Waveguide
6x6", rotatable
Passive Power Handling
1400W peak
