Electro-Voice EVF-2151D Subwoofer Dual 15" Front-Loaded Passive Subwoofer | Black

Electro-Voice EVF-2151D Subwoofer Dual 15" Front-Loaded Passive Subwoofer | Black

SoundPro Item: 45384 | Part Number: F.01U.272.935

$4,815.00
$4,815.00 $4,815.00
Your Price Sold out
MSRP: $4,815.00 | MAP: $4,815.00

Usually ships in 5-7 business days

  • Dual DVX3159A Transducers Deliver Omnidirectional Coverage Across The Full Operating Bandwidth
  • Twenty-Eight M10 Threaded Suspension Points Enable Flexible Rigging And Array Configurations
  • Weather-Resistant Birch Enclosure Meets IEC 60529 IP44 For Semi-Outdoor Installations
  • Trapezoidal Geometry Supports Tight Packing In Cardioid And End-Fire Subwoofer Arrays
  • Four-Thousand-Watt Peak Power Handling Supports High-Output Line Array And Distributed Systems
Log in or register for YOUR best price

The Electro-Voice EVF-2151D serves integrators and venue operators who need uncompromising bass extension in fixed installations where floor space is limited but sonic impact cannot be compromised. Dual 15" DVX3159A transducers in a front-loaded configuration provide omnidirectional low-frequency energy distribution across the full operating bandwidth, eliminating the coverage gaps common in directional subwoofer designs. The 13-ply weather-resistant birch cabinet withstands the rigors of touring-grade portable use while meeting IEC 60529 IP44 environmental protection for semi-outdoor installation.

Twenty-eight M10 threaded suspension points enable flexible rigging configurations for flown arrays, ground-stacked clusters, or hybrid deployments. The trapezoidal geometry permits tight packing in cardioid and end-fire arrangements without sacrificing internal volume. Continuous power handling of 1000 watts and 4000-watt peak capacity support high-output line arrays and distributed systems in theaters, houses of worship, performing arts centers, and corporate venues where predictable low-frequency behavior across all seating zones is non-negotiable.

Downloads

View full details

Specifications

Performance
Frequency Range (-10 dB)
30 Hz – 3.2 kHz
Frequency Response (-3 dB)
40 Hz – 2.6 kHz
Sensitivity 1 W/1 m
101 dB
Max SPL/1 m
137 dB
Coverage (Nominal -6 dB) H
360°
Coverage (Nominal -6 dB) V
Omnidirectional
Recommended High-Pass Frequency
35 Hz
Audio
LF Transducer
Two 15" DVX3159A drivers
Speaker Type
Subwoofer
Nominal Impedance
4 ohms
Minimum Impedance
Passive: N/A, Biamp: 2.7 ohms
Nominal Impedance (Passive)
Passive: N/A, Biamp: 4 ohms
System Power Handling (Continuous/Program/Peak)
1000 W, 2000 W, 4000 W
Passive Power Handling
4000 W
Construction
Enclosure Material
13-ply weather-resistant birch
Grille
16 ga Galvanneal, Powdercoat with screen behind; PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind
Suspension
28 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)
Connectivity
Input Connections
Euroblock; PI and FG versions include dual gland nut input panel cover
Environmental
Weatherized
No
Environmental Specs
Standard versions: IEC 60529 IP44; PI and FG versions: IEC 60529 IP55
Dimensions
Height
30.26" (768.6 mm)
Width
26.6" (675.6 mm)
Depth
28.6" (726.4 mm)
Dimensions (H x W x D)
30.26" x 26.6" x 28.6" (768.6 x 675.6 x 726.4 mm)
Weight
Net Weight
117 lbs (53.1 kg)
