Specifications
Audio
Generation Element
Dual condenser, back-electret
Frequency Response
50 Hz to 20,000 Hz
Polar Patterns
Omnidirectional, Cardioid, Supercardioid, Hypercardioid
Sensitivity
5.6 mV/Pascal at 1 kHz
Clipping Level (1% THD)
>127 dB SPL
Equivalent Noise
<26 dB SPL A-weighted
Dynamic Range
>101 dB
Output Impedance (1 kHz)
200 Ohms
Electrical
Power Requirements
Phantom, 12-52 VDC
Current Consumption
<5 mA with P48 supply
Polarity
Pin 2 positive, referenced to Pin 3, with positive pressure on diaphragm
Controls
Switches
Top-mounted momentary push button, push on/off or PTT/PTM selector, power-up on/off selector, high-pass enable, 4-position polar pattern selector
Dimensions
Gooseneck Length PC Plus-12
305 mm (12")
Gooseneck Length PC Plus-18
457 mm (18")
Maximum Head Diameter
14.6 mm (0.58")
Gooseneck Diameter Lower Section
7.9 mm (0.31")
Gooseneck Diameter Upper Section
6.4 mm (0.25")
Shipping
Shipping Weight PC Plus-12
201 grams (7.1 oz)
Shipping Weight PC Plus-18
210 grams (7.4 oz)
Construction
Color
Non-reflecting black
Included Items
Accessories Furnished
Windscreen, two-piece shock mount, flush mount parts kit
