Specifications
Audio
Frequency Response (-3 dB)
63 Hz - 18,000 Hz
Frequency Range (-10 dB)
50 Hz - 20,000 Hz
Maximum SPL (1 m)
125 dB
Coverage Angle (H x V)
90° x 60°
Crossover Frequency
2.2 kHz
Electrical
Amplifier Rating
1000 W
Power Consumption
100 - 240 V~, 50 - 60 Hz, 1.0 - 0.5 A
Connectivity
Inputs
2x XLR Combo mic/line
Output
1x XLR mix output
Transducers
LF Driver Size
12 in
LF Driver Type
WECA2124H woofer
LF Driver Magnet
Ferrite
HF Driver Size
1 in
HF Driver Type
DENA2504H compression driver
HF Diaphragm Material
Titanium-coated PEI
HF Driver Magnet
Neodymium
Construction
Enclosure
Composite
Grille Material
Powder coated steel
Color
Black
Dimensions
Exterior H x W x D (in)
23.74 in x 13.89 in x 13.86 in
Exterior H x W x D (mm)
603 mm x 353 mm x 352 mm
Shipping H x W x D (in)
25.39 in x 16.14 in x 16.14 in
Shipping H x W x D (mm)
645 mm x 410 mm x 410 mm
Weight
Product Weight
26.5 lbs (12.0 kg)
Shipping Weight
34.2 lbs (15.5 kg)
