Specifications
Audio
Frequency Response (-3 dB)
56 Hz - 17,000 Hz
Frequency Range (-10 dB)
45 Hz - 20,000 Hz
Maximum SPL (1 m)
126 dB
Coverage Angle (H x V)
90° x 60°
Crossover Frequency
1.9 kHz
Electrical
Amplifier Rating
1000 W
Power Consumption
100 - 240 V~, 50 - 60 Hz, 1.0 - 0.5 A
Connectivity
Inputs
2x XLR Combo mic/line
Output
1x XLR mix output
Construction
LF Transducer Size
15 in
LF Transducer Type
WECA2154H woofer
LF Transducer Magnet Material
Ferrite
HF Transducer Size
1 in
HF Transducer Type
DENA2504H compression driver
HF Transducer Diaphragm Material
Titanium-coated PEI
HF Transducer Magnet Material
Neodymium
Enclosure
Composite
Grille Material
Powder coated steel
Color
Black
Dimensions
Product Dimensions (H x W x D)
28.54" x 16.77" x 15.83"
Product Dimensions (H x W x D) (mm)
725 mm x 426 mm x 402 mm
Shipping Dimensions (H x W x D)
30.00" x 19.10" x 17.91"
Shipping Dimensions (H x W x D) (mm)
762 mm x 485 mm x 455 mm
Weight
Product Weight
32.2 lbs
Product Weight (kg)
14.6 kg
Shipping Weight
43.0 lbs
Shipping Weight (kg)
19.5 kg
