Specifications
Dimensions
Transducer (quantity) Size
(12) 2.5 in mid-high drivers (2) 6.5 in woofers in band-pass
Dimensions (H X W X D)
37.4 in x 7.28 in x 9.84 in
Electrical
Peak Input Voltage (Lo-Z) )
145 V
Nominal Impedance (Lo-Z)
8 Ω
Audio
Max SPL
129 dB
Axial Sensitivity
92 dB
Connectivity
Connector Type
4-pin Phoenix/Euroblock Input + Pass through
Construction
Mounting
SwifTilt Multi-angle Tilt + Pan Bracket
Color
RAL 9004 black / RAL 9003 white
Environmental
IP Rating
FW (outdoor full exposure), IP55
Shipping
Weight
33.1 lb
General
Frequency Range (-10 Db, Half space)
45 Hz - 16 kHz
Acoustic Down-tilt (relative to horizontal)
-7.5°
Coverage Angle(H X V)
140° x 25° (narrow) / 45° (wide);
Power Handling (continuous)
300 W
Power Handling (program)
600 W
Recommended High-pass
≥50 Hz Butterworth, 24 dB/oct
Transformer Taps 70 V line)\
N/A
Transformer Taps 100 V Line
N/A W
Suspension Points
(4) M8
Maximum Horizontal Pan Angle
+/- 80° (at all down-tilt angles)
Vertical Down-tilt Angles
0°, 2.5°, 5°, 7.5°, 10°, 15°, 20°, 25°
Mechanical
Wire Size
10AWG (maximum)
