Specifications
Dimensions
Dimensions (length, Diameter, Shank
7.6 x 1.95 x 0.96 inches (192 x 49.5 x 24.3 mm)
Weight
Net Weight
11.5 oz (326 g)
Shipping Weight
1 lb 4.9 oz (593 g)
Electrical
Sensitivity, Open Circuit (voltage, 1 kHz)
5.6 mV/Pascal (-45 dBV/Pa)
Power Requirements
48 VDC phantom power
Electrical Contact
3-pin, XLR-type
Audio
Polar Pattern
Cardioid
Frequency Response
50 Hz - 20 kHz
Output Impedance
200 ohms
Clipping (max SPL)
149 dB SPL (1% THD)
Self Noise
22 dB SPL "A" weighed (0 dB=20 μPa)
Signal-to-Noise Ratio
72 dB
Construction
Finish
Black polyurethane paint
General
Transducer Type
Condenser
Dynamic Range
127 dB
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3
