Specifications
Dimensions
Dimensions (HxWxD)
23.1x16.9x12.3"
Electrical
Min Impedance
5Ω
Nominal Impedance (passive)
8Ω
Audio
Speaker Type
full-range, two-way
Max. SPL/1m (calc)
131/123dB (Low Z/100V)
Power Rating
300W
Crossover Frequency
1500Hz
Sensitivity 1W/1 M
99dB
Axial Sensitivity (SPL, 1W @ 1 m)
99dB
Connectivity
Input Connections
2x four-pin Speakon
Construction
Woofer Size
12"
Shipping
Weight
39 lbs
General
Frequency Range (-10dB)
50 - 20000kHz
HF Transducer
1.25" DH3/2010A
Coverage (nominal -6dB)
H 65° V 65°(Const.-dir. horn)
LF Transducer
12" DL12BFH
System Power Handling (continuous/program/peak)
300/1200watts
Directivity Index
11.1dB (+2.4/-4.1 dB)
