• Electro-Voice SX300PIX 12'' Weather-Resistant Passive Speaker
1 1

Electro-Voice SX300PIX 12-Inch Weather-Resistant Passive Speaker | Color: White

Electro-Voice SX300PIX 12-Inch Weather-Resistant Passive Speaker | Color: White

SoundPro Item: 42141 | Part Number: F.01U.265.564

$2,162.00
$2,162.00 $2,162.00
Your Price Sold out
MSRP: $2,162.00 | MAP: $2,162.00

Usually ships in 5-7 business days

  • Sx300 performance with enhanced weather-resistance
  • PIX version has multi-tap transformer for 70 or 100V use
  • Ideal for installation, alone or in arrays
  • 1.25" DH3/2010A titanium HF compression driver
  • 65°x65° Constant-directivity Varipath™ horn
  • Ring-Mode Decoupling (RMD™) for increased intelligibility
  • Neutrik Speakon® (PI) or Phoenix (PIX) connectors
  • Trapezoidal enclosure of high-impact polypropylene
  • Rubber feet and mating sockets for stacking
  • Integral handles, pole socket, suspension points
Log in or register for YOUR best price

With a weather-resistant design that makes it a great choice for outdoor venues or events, The Electro-Voice SX300PIX is a 300-watt, 12-inch two-way, high-efficiency, constant-directivity compact speaker system with Ring-Mode Decoupling (RMDTM). Through the extensive use of computer-aided design and modeling, Electro-Voice engineers have developed a state-of-the-art professional loudspeaker system.

Passive speakers are ideal for when you need flexibility and customization options, such as in professional applications where the sound system needs to be scalable and versatile, or for audio projects that require the most accurate and reliable sound reproduction. With more space inside their housing, passive speakers can accommodate larger drivers, resulting in a more pristine, accurate sound reproduction where it’s needed most.

View full details

Specifications

Dimensions
Chassis Size
12"
Dimensions (HxWxD)
23.1x16.9x12.3"
Electrical
Min Impedance
5Ω
Nominal Impedance (passive)
8Ω
Audio
Speaker Type
full-range, mid-high, 2-way
Max SPL/1m
131/123dB (Low Z/100V)
Power Rating
300W
Crossover Frequency
1500Hz
Sensitivity 1 W/1m
99dB
Axial Sensitivity (SPL, 1W @ 1m)
99dB
Connectivity
Input Connections
2x 4-pin Speakon
Construction
Woofer Size
12"
Shipping
Weight
39 lbs
General
HF Transducer
1.25" DH3/2010A
Coverage (nominal -6dB)
H 65°, V 65° (const. -dir. horn)
LF Transducer
12" DL12BFH
Directivity Index
11.1dB (+2.4/-4.1 dB)
RF
Frequency Range
50 - 20000kHz (-10dB)
