Specifications
Dimensions
Dimensions (WxDxH) Including Feet
23.1" x 19.4" x 8.6"
Electrical
Power Supply Voltage
100 – 120 V ± 10%, 50/60 Hz AC
Connectivity
Color Light Output
13,000 lumens
White Light Output
13,000 lumens
Input Signal
Input Video Signal (HDMI®, DVI-D and HDBaseT™ ports) 480i/480p/ 576i/576p/ 720p/ 1080i/1080p/ 3840 x 2160/ 4096 x 2160
Network Standby
2W
Construction
Color Reproduction
up to 1.07 billion colors
Controls
Maximum Display Resolution
4096 x 2160 (resizing display)
Display Resolution
1920 x 1200 pixels
Environmental
Operating Temperature
32° to 122°F (0° to 50°C)
Shipping
Weight
52.4 pounds
General
Projection System
High-aperture Epson 3LCD, 3-chip technology
Projection Method
front/rear/ceiling mount
Driving Method
poly-silicon TFT Active Matrix
Pixel Number
2,304,000 dots (1920 x 1200) x 3
Native Resolution*1
WUXGA with 4K Enhancement/4.6 million pixels
Aspect Ratio
supports 4:3, 16:9, 16:10
Pixel Arrangement
cross stripe
Contrast Ratio
2,500,000:1 (Dynamic Contrast: On)
Brightness Uniformity (typical)
85%
Vertical
±60%
Horizontal
±18%
Illumination Technology
laser diode
Normal/Custom
886W
Quiet/Extended
646W
Energy Saving Standby
0.4W
Fan Noise
34dB (normal mode), 29dB (ECO mode)
Security
Security cable hole, lens lock, Kensington®lock provision, wireless LAN unit lock
Remote Control
Features, Operating Angle
Operating Distance
98 ft
*1
4K Enhancement Technology shifts each pixel to surpass Full HD resolution on screen
*2
Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118
*3
No required maintenance for the light source for up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 - 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period.
*4
HDR performance available with select third-party devices. For more information, see www.epson.com/hdrcompatibility
*5
NFC requires use of a device that includes NFC, and may require additional software
*6
Internet connection required for download. Data usage fee may apply
*7
Requires Epson external camera or built-in camera for each projector and the Epson Projector Professional Tool app
*8
Using separate camera for each projector
*9
IP5X-certified optical engine and laser light source module in accordance with IEC standard 60529
*10
For convenient and reasonable recycling options, visit www.epson.com/recycle
*11
SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency
