Specifications
Dimensions
Size - Projected Distance
30" to 300" (2.2 to 27.2 ft)
Focal Length
14.06 – 16.82 mm
Electrical
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz
Power Consumption
309 W (Normal Mode), 217 W (ECO Mode)
Audio
Audio Output
1 W mono speaker
Optics
Lamp Type
214 W UHE
Lamp Life
7,000 hours (ECO Mode), 4,000 hours (Normal Mode)
Zoom Ratio
Optical zoom 1.0 – 1.2
Connectivity
Color Brightness - Color Light Output
3,200 lumens
White Brightness - White Light Output
3,200 lumens
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/SECAM SDTV/HDTV
USB Type a
1x PC-free USB and other
USB Type B
1x USB Plug ‘n Play
Construction
Color Reproduction
Up to 1.07 billion colors
Controls
Display Performance NTSC
480 linePAL: 576 line(depends on observation of the multi-burst pattern)
Environmental
Operating Temperature
41 ° to 95 °F (5 ° to 35 °C)
Shipping
Weight
4 lbs
General
Projection System
RGB liquid crystal shutter projection system
Projection Method
Front/rear ceiling mount, Front/rear desktop
Driving Method
Poly-silicon TFT Active Matrix
Pixel Number
2,073,600 dots (1920 x 1080) x 3
Aspect Ratio
16:9
Resolution
1920 x 1080 (1080p)
Resize
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 800 (WXGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+),1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
Throw Ratio Range
1.02 – 1.23
Keystone Correction
Automatic Vertical: ± 30 degrees, Automatic Horizontal: ± 20 degrees
Contrast Ratio
Up to 10,000:1
Type
Optical Zoom (Manual)/ Focus (Powered)
F-number
1.58 – 1.70
Interfaces
1x HDMI (Supports MHL® connectivity)
Computer/component Video
1x D-sub 15 pin
Composite Video
1x RCA
Fan Noise
39 dB (Normal Mode), 30 dB (ECO Mode)
Features
Power, Source Search Selection, Computer, Video, A/V Mute, Freeze, User ID, Auto, Aspect, Color Mode, NUM, Page Up and Down, E-zoom, Volume, Help, Menu, Enter, ESC and Pointer functions
Operating Distance
19.7 ft
Operating Angle Right/left
Front: ± 60 degrees; rear: ± 30 degreesUpper/lower: Front: ± 30 degrees; rear: ± 30 degrees
