- Source
- LED details: 40 Lumileds LUXEON® Z LED
- Max lumens: 2429
- Lumens per watt: 27.6
- L70 rating (hours to 70% output)*: 55,000 hours
- Color
- Colors used: red, green, indigo, lime
- Color temperature range: Color mixing
- Calibrated array: Yes
- Red shift: No
- Optical
- Beam angle range 15.3° (secondary lenses available for multiple beam-spread options)
- Gate size: N/A
- Aperture size: 7.5 in / 190 mm
- Pattern projection: No
- Pattern size: N/A
- Camera flicker control/Hz range: 1,200 Hz (default) ; 25,000 Hz (via RDM)
- Control
- Input method DMX512 via 5-pin XLR connector
- Protocols DMX512/RDM
- Modes (footprint) 4 modes, see page 7
- RDM configuration Yes
- UI type Seven-segment, three-button interface
- Local control Yes
- Onboard presets Yes (12)
- Onboard sequences Yes (5)
- Onboard effects No
- Fixture-to-fixture control Yes
- Notes 15-bit virtual dimming engine
- Electrical
- Voltage range 100-240 VAC 50/60 Hz
- Input method powerCON power in and thru
- Inrush
- 35A at 120V (First half-cycle)
- 49A at 240V (First half-cycle)
- Fixtures per circuit* (All measurements are for 120V, 60 Hz. Results may vary in different regions.)
- 9 (15 A power thru connector)
- 10 (R20 module or similar)
- Wattage typical
- 90W at 120V
- 89W at 240V
- Current draw
- 0.75A at 120V
- 0.40A at 240V
- Thermal
- Ambient operating temp: 0°-40°C (32°-104°F)
- Fan (controllable): Yes (No)
- Droop compensation: Yes
- dB range: 24.8 dBA average at 1 m
- BTUs/hour (RGB-L / DB): 307 / 303
- Physical
- Materials: Die-cast, all metal housing
- Color options: Black, white, silver, or custom color
- Mounting options: Yoke, floor stand yoke (available as an accessory)
- IP rating: IP20
- Weight: 3.77 kg (8.3 lbs)
- User interface: Seven-segment, three-button interface
- Warranty
- Fixture 5 years
- LED array 10 years
- Regulatory and Compliance: Approved regulatory standards
- cETLus Listed
- Conforms to UL 1573 Listed
- Conforms to UL 924 Listed
- Certified to CSA C22.2 No. 166 Listed
- Certified to CSA C22.2 No. 141 Listed
- CE Compliant
- EAC Compliant
- Dimensions (HxWxD)12.2x7.98x9.45" (310x203x240mm)
- Weight8.3 lbs (3.8kg)
- Shipping Weight10.1 lbs (4.6kg)
