ETC CSSPOTVXTMV-1 ColorSource Spot VXT ETL Engine Only Outdoor LED Spot Light | White

ETC CSSPOTVXTMV-1 ColorSource Spot VXT ETL Engine Only Outdoor LED Spot Light | White

SoundPro Item: 151374 | Part Number: CSSPOTVXTMV-1

$2,875.00
$2,875.00 $2,875.00
Your Price Sold out
MSRP: $2,875.00 | MAP: $2,875.00

Usually ships in 5-7 business days

  • IP65 Housing For Outdoor Reliability
  • RGBIL Array For Richer Mixed Color
  • Wireless Setup Helps Speed Configuration
  • Source Four Compatibility Protects Inventory
  • Multiverse DMX/RDM Supports Flexible Control
  • All-Metal Housing Aids Long-Term Durability
  • Long Warranty Adds Deployment Confidence
Log in or register for YOUR best price

The ETC CSSPOTVXTMV-1 ColorSource Spot VXT is an IP65-rated LED spot fixture built for venues that need reliable output outdoors or in demanding installed environments. It uses a five-color red, green, blue, indigo, and lime array to deliver both soft pastel looks and deeply saturated color from a single luminaire. For performance spaces, houses of worship, schools, facades, retail installations, and exhibition venues, it offers the flexibility to support theatrical-style beam control while standing up to weather exposure.

This fixture is designed to simplify deployment in systems where speed and consistency matter. Wireless configuration through the Set Light app and NFC streamlines addressing and setup, while DMX/RDM and Multiverse wireless DMX/RDM support make it easier to integrate into modern lighting networks. Existing Source Four lens tubes and accessories can be used with the fixture, helping teams extend current inventories instead of replacing established optical workflows.

With up to 8,896 lumens, a 54,000-hour L70 rating, controllable fan operation, LED droop compensation, and an all-metal die-cast housing, the ColorSource Spot VXT fits applications that demand dependable output, practical service life, and installation-ready construction. Included accessories support immediate deployment with a hanging yoke, 1.5 m power cable, and soft-focus diffuser in an A-size gobo holder.

Downloads

View full details

Specifications

Source
LED Details
60 Lumileds LUXEON® C and LUXEON Rebel LEDs
Max Lumens
8,896
Lumens Per Watt
37.3
L70 Rating
54,000 hours
Color
Colors Used
Red, green, blue, indigo, lime
Color Temperature Range
Color mixing
Calibrated Array
Yes
Red Shift
No
Optical
Beam Angle Range
Swappable lens tubes, 5–90 degrees
Gate Size
80 mm
Aperture Size
6.25–14 in (depending on lens tube)
Pattern Projection
Yes
Pattern Size
A or B
Camera Flicker Control/Hz Range
5,000 Hz (default) and 25,000 Hz (via RDM)
Notes
Can use LED CYC adapter; Fresnel adapter NOT supported
Control
Input Method
5-Pin XLR (IP rated), Multiverse wireless and NFC
Protocols
DMX-512, RDM, City Theatrical Multiverse, NFC
Modes (Footprint)
5 modes
RDM Configuration
Yes
UI Type
N/A
Local Control
via Set Light only
Onboard Presets
Yes (12)
Onboard Sequences
Yes (5)
Onboard Effects
No
FixtureLink
Yes
Notes
15-bit virtual dimming engine
Wireless
Band
2.400–2.480 GHz
Range
100 m indoors, 500 m line of sight (subject to conditions)
Max Receivers
DMX: No limit / RDM: Varies / Multiverse SHoW Baby®: 585 / Multiverse Transmitter: 5,000
Broadcast Power
100 mW
Electrical
Voltage Range
100–240 VAC 50/60 Hz
Input Method
powerCON TRUE1 TOP power in and thru
Inrush
7.02 A at 120 V (first half-cycle); 19.5 A at 240 V (first half-cycle)
Fixtures Per Circuit
6 fixtures (R20 module or similar)
Wattage Typical / Standby
240.8 W / 3.6 W at 100 V; 238.5 W / 3.6 W at 120 V; 236 W / 2.9 W at 240 V
Current Draw Typical / Standby
2.45 A / 0.1 A at 100 V; 2.02 A / 0.11 A at 120 V; 1.06 A / 0.17 A at 240 V
Thermal
Ambient Operating Temp
-20°C to 40°C (-4°F to 104°F)
Fan (Controllable)
Yes (yes)
Droop Compensation
Yes
dB Range
26.3 dBA average at 1 m
BTUs/Hour
813
Physical
Materials
Die-cast, all metal housing
Color Options
Black, white, silver, or custom color
Mounting Options
Yoke
IP Rating
IP65
Weight
10.8 kg (23.7 lb) (without lens)
Included Accessories
Hanging yoke, 1.5 m power cable, soft-focus diffuser in an A-size gobo holder
Warranty
Fixture
5 years
LED Array
10 years
Regulatory And Compliance
Approved Regulatory Standards
cULus Listed; CE and UKCA compliant
