ETC ECPB DMX OUT / A/C DMX Output Wall Plate Control Plug-In Station | 2-gang

ETC ECPB DMX OUT / A/C DMX Output Wall Plate Control Plug-In Station | 2-gang

SoundPro Item: 127555 | Part Number: ECPB DMX OUT / A/C

$295.00
$295.00 $295.00
Your Price Sold out
MSRP: $295.00 | MAP: $295.00

Usually ships in 5-7 business days

  • Adds DMX Output At Remote Control Locations
  • Includes Duplex Edison Outlet For Local Power
  • Supports Surface Or Flush Mount Installation
  • Fits Standard RACO Back Boxes In Most Models
  • Scratch-Resistant Finish Helps In Demanding Venues
  • Terminal Blocks Included For Contractor Wiring
Log in or register for YOUR best price

The ETC ECPB DMX OUT / A/C is an Electronic Control Plug-in Box designed to add a convenient DMX512 output connection and local AC power at key points in a lighting system installation. It is intended for venues that need distributed control access for production, maintenance, or temporary equipment tie-ins, including theatres, auditoriums, television studios, houses of worship, museums, casinos, and hospitality spaces.

This model supports surface or flush mounting, and most configurations fit standard RACO back boxes, helping streamline planning for permanent installations. ETC also provides surface-mount back box options, and an optional U-bolt pipe-mount kit can be used with surface-mount back boxes when wall mounting is not practical. For contractor installation, terminal blocks are supplied, low-voltage Class 2 wiring is used for data connections, and voltage barriers are provided when Class 1 and Class 2 terminations share the same faceplate.

The faceplate is made from 0.80 in aluminum and finished in a fine-texture, scratch-resistant black powder coat with white legends standard. DMX inputs and outputs support termination of Belden 9729 or equivalent cable, as well as Category5 cable. Custom configurations are available for certain connector types, making the ECPB series a flexible choice for facilities that need reliable connection points throughout a venue.

Downloads

View full details

Specifications

Physical
Faceplate Material
0.80 in aluminum
Finish
Fine texture, scratch-resistant black powder coat
Legends
White legends standard
Custom Legends
Engraving or custom legends available
Mounting
Surface or flush mount
Flush-Mount Compatibility
Most models fit standard RACO back boxes
Surface-Mount Back Boxes
Available from ETC
Pipe-Mount Option
Optional U-Bolt Pipe-mount kit for use with surface-mount back boxes
Electrical
Data Wiring
Low voltage class 2 wiring for data connections
Voltage Barriers
Provided when Class 1 and Class 2 wiring terminations are included in the same faceplate
Terminations
Terminal blocks supplied for contractor terminations
Connector Options
DMX Output Connector
5-Pin XLR socket connectors
AC Outlet
Duplex Edison AC power outlet
Supported Cable
Belden 9729 (or equivalent) or Category5 cable
Station Wall Plate Dimensions
Single Gang
2.75 in (70 mm) W x 4.50 in (114 mm) H x 2.50 in (64 mm) D
Two Gang
4.56 in (115 mm) W x 4.50 in (114 mm) H x 2.50 in (64 mm) D
Three Gang
6.38 in (162 mm) W x 4.50 in (114 mm) H x 3.50 in (89 mm) D
Four Gang
8.18 in (208 mm) W x 4.50 in (114 mm) H x 3.50 in (89 mm) D
Five Gang
10.00 in (254 mm) W x 4.50 in (114 mm) H x 3.50 in (89 mm) D
Six Gang
11.81 in (300 mm) W x 4.50 in (114 mm) H x 3.50 in (89 mm) D
Seven Gang
13.63 in (346 mm) W x 4.50 in (114 mm) H x 3.50 in (89 mm) D
Flush-Mount Back Boxes
Single Gang
RACO 690 or equivalent
Two Gang
RACO 691 or equivalent
Three Gang
RACO 697 or equivalent
Four Gang
RACO 698 or equivalent
Five Gang
RACO 699 or equivalent
Six Gang
RACO 965 or equivalent
Seven Gang
Provided by ETC
Regulatory And Compliance
Listing
ETL Listed
