ETC S4WRDPAR Static Wash Fixture Body For S4WRD II | Black

ETC S4WRDPAR Static Wash Fixture Body For S4WRD II | Black

SoundPro Item: 116750 | Part Number: S4WRDPAR

$335.00
$335.00 $335.00
Your Price Sold out
MSRP: $335.00 | MAP: $335.00

Usually ships in 5-7 business days

  • Built For Source 4WRD II Retrofit Use
  • Creates Soft PAR-Style Wash Coverage
  • Supports Familiar Accessory Workflows
  • Reduces Power Demand Versus HPL Versions
  • Cool Operation Helps In Installed Spaces
  • Enables DMX Or Line Voltage Dimming
Log in or register for YOUR best price

The ETC S4WRDPAR is a static wash fixture body designed for use with the Source 4WRD II LED retrofit system. It gives lighting teams a practical way to configure Source 4WRD II into a PAR-style wash fixture for soft, even field coverage in multipurpose rooms, worship environments, education spaces, hospitality venues, retail applications, clubs, and exhibition settings. For organizations standardizing around the Source 4WRD II platform, this body supports a consistent approach to fixture deployment while extending the usefulness of the LED engine across different beam needs.

This fixture body works like a traditional Source Four PAR or PARNel and accepts the same accessory approach, helping technicians and integrators maintain familiar workflows. It also benefits from the Source 4WRD II platform’s efficient operation, cooler running temperatures, DMX dimming or line voltage dimming, and the elimination of lamp changes. At full output, the system draws 155 W and is specified as brighter than 750 W HPL versions, making it well suited for users seeking lower power consumption without giving up practical output for front wash, area lighting, or general stage coverage.

Downloads

View full details

Specifications

Source
LED details
S4WRD II LED *Not Included*
Max lumens
11,584 (PAR), 10,786 (PARNel) w/ S4WRD II
Lumens per watt
77 (PAR), 72 (PARNel)
L70 rating (hours to 70% output)
>45,000 hours (LM84 test pending)
Notes
S4WRD II LED sold separately
Electrical
Voltage range
114–125 V, 60 Hz (120 VAC); 209–252 V, 50 Hz (230 VAC)
Input method
Hard wired, 1 m cord, Edison plug (120 VAC); Hard wired, 1 m cord, bare end (230 VAC)
Inrush
30 A (first half-cycle) at 120 VAC; 12 A (first half-cycle) at 230 VAC
Fixtures per circuit
120 VAC: 14 fixtures per 20 A switched circuit (R20 module or similar)
Fixtures per circuit
230 VAC: 6 fixtures per non-dimmed circuit
Included / Optics
Color frame
Lens
PAR ships with AR coated flat lens (other lenses sold separately); PARNel ships with PARNel lenses
