Specifications
COMPLIANCE
EN 54-24 Certified
Yes
Safety Agency Ratings
EN 54-24 Certified: EN 54-24: 2008, Loudspeaker for Voice Alarm Systems for Fire Detection and Fire Alarm Systems for Buildings
PHYSICAL
Colors
Black (similar to RAL 9005), white (similar to RAL 9003)
Enclosure Material
Engineered plastics
Environmental
Indoor only
Grille
Perforated steel, powder-coated finish
Logo
Removable
Suspension/Mounting
1 suspension attachment point, 1 safety cable attachment point
Operating Temperature Range
0 °C to 50 °C (32 °F to 122 °F)
Product Dimensions (HxWxD)
5.9 in x 7.2 in (149 mm x 183 mm), loudspeaker diameter x depth / 15.0 ft x 0.1 in (4.6 m x 2 mm), suspension cable length x diameter
Net Weight
3.3 lb (1.5 kg), loudspeaker with grille (single)
Shipping Weight
9.0 lb (4.1 kg), pair
PERFORMANCE
Frequency Range (-10 dB)
83 - 19,000 Hz
Coverage, Horizontal
140°
Calculated Maximum SPL @ 1 m
99 dB
Nominal Impedance
16 Ω (transformer bypass)
Power Handling, long-term continuous
16 W
Power Handling, Peak
64 W
Sensitivity (SPL/1 W at 1 m)
87 dB
Transformer Taps, 100V
2, 4, 8, 16 W, bypass
Transformer Taps, 70V
1 W, 2 W, 4 W, 8 W, 16 W, bypass
Coverage, Vertical
140°
TRANSDUCERS
Driver Protection
Recommended high-pass protection 85 Hz with minimum 24-dB/octave filter
Low-Frequency
1 x 2.25 in (57 mm) woofer
