Specifications
COMPLIANCE
EN 54-24 Certified
Yes
Safety Agency Ratings
EN 54-24: 2008 for Voice Alarm Systems; UL 1480(A); NFPA 70 & NFPA 72; CSA C22.1 Section 32
PHYSICAL
Colors
Black (similar to RAL 9005), white (similar to RAL 9003)
Enclosure Material
Engineered plastics, highly UV fade-resistant
Grille
Perforated steel, powder-coated finish, tamper-resistant design
Ingress Protection
IP55
Logo
Removable
Operating Temperature Range
-25 °C to 70 °C (-13 °F to 158 °F)
Product Dimensions (HxWxD)
7.1 in x 4.4 in x 4.5 in (182 mm x 113 mm x 114 mm), loudspeaker / 7.7 in x 4.4 in x 5.3 in (196 mm x 113 mm x 135 mm), loudspeaker with bracket
Net Weight
3.2 lb (1.4 kg), loudspeaker with grille & bracket (single)
Shipping Weight
9.2 lb (4.2 kg), pair
PERFORMANCE
Frequency Range (-10 dB)
83 - 19,000 Hz
Coverage, Horizontal
145°
Calculated Maximum SPL @ 1 m
99 dB
Nominal Impedance
16 Ω (transformer bypass)
Power Handling, long-term continuous
16 W
Power Handling, Peak
64 W
Sensitivity (SPL/1 W at 1 m)
87 dB
Transformer Taps, 100V
2, 4, 8, 16 W, bypass
Transformer Taps, 70V
1 W, 2 W, 4 W, 8 W, 16 W, bypass
Coverage, Vertical
140°
TRANSDUCERS
Driver Protection
Recommended high-pass protection 85 Hz with minimum 24-dB/octave filter
Low-Frequency
1 x 2.25 in (57 mm) woofer
