Specifications
COMPLIANCE
EN 54-24 Certified
Yes
Safety Agency Ratings
EN 54-24: 2008 for Voice Alarm Systems; UL 1480(A); NFPA 70 & NFPA 72; CSA C22.1 Section 32
PHYSICAL
Colors
Black (similar to RAL 9005), white (similar to RAL 9003)
Enclosure Material
Engineered plastics, highly UV fade-resistant
Grille
Steel, powder-coated finish
Ingress Protection
IP55
Logo
Rotatable, removable
Operating Temperature Range
-25 °C to 70 °C (-13 °F to 158 °F)
Product Dimensions (HxWxD)
10.0 in x 6.7 in x 6.8 in (254 mm x 171 mm x 174 mm), loudspeaker / 10.7 in x 6.7 in x 7.7 in (273 mm x 171 mm x 196 mm), loudspeaker with bracket
Net Weight
6.8 lb (3.1 kg), loudspeaker with grille & bracket (single)
Shipping Weight
18.4 lb (8.3 kg). pair
PERFORMANCE
Frequency Range (-10 dB)
70 - 17,000 Hz
Coverage, Horizontal
130°
Calculated Maximum SPL @ 1 m
105 dB
Nominal Impedance
8 Ω (transformer bypass)
Power Handling, long-term continuous
40 W
Power Handling, Peak
160 W
Sensitivity (SPL/1 W at 1 m)
89 dB
Transformer Taps, 100V
5, 10, 20, 40 W, bypass
Transformer Taps, 70V
2.5 W, 5 W, 10 W, 20 W, 40 W, bypass
Coverage, Vertical
125°
TRANSDUCERS
Driver Protection
Recommended high-pass protection 70 Hz with minimum 24-dB/octave filter
Low-Frequency
1 x 4.5 in (114 mm) woofer
