Furman ELITE-15 PFI 15A Power Factor Power Conditioner
Furman ELITE-15 PFI 15A Power Factor Power Conditioner
Soundpro Item: 82047 | Part Number: ELITE-15 PF I
- SMP provides the highest level of protection available
- LiFT significantly reduces AC line noise
- E.V.S. protects equipment from dangerous overvoltage conditions
- Zero ground contamination circuitry protects critical digital components
- Power Factor Technology provides over 45 amps peak charge surplus current for power-starved amplifiers
- Retractable LED lamps illuminate a cabinet or rack full of equipment
- 12 volt triggering for remote control
Couldn't load pickup availability
Though the need for pristine AC power is nothing new, the Elite-15 Power Factor i's technology and its unique implementation are revolutionary and without peer.
The extreme AC demands encountered in the professional audio/video arena have required technological developments far in excess of typical home theater/audiophile power products. In studios, live sound, and broadcast facilities, breakdown is unacceptable. Equipment failure or poor performance is costly. The same is true of today's home theater. Our solution based technology, extensive engineering expertise, and robust build quality have answered the challenge of today's corrupted power lines, and led to the creation of the Elite-15 PF i.
Specifications
- General
- Family: Elite Series
- Line Voltage: 120 (Volts)
- Number of Outlets: 13
- Number of Isolated Banks: 3
- Outlet Descriptions
- 1 (linearly filtered outlet, front panel)
- 4 (linearly filtered audio-video outlets, 2 switched via 12V trigger)
- 4 (linearly filtered outlets with additional ultrasonic filtering for video components, 2 switched via 12 V trigger)
- 4 (Power Factor Technology amplifier outlets, 3 amps RMS reserve, reactive load, over 45 amps peak charge, 2 switched with 5 second delay via 12V trigger)
- Rack Mountable: Yes
- Rack Ears Included: Yes
- Front Panel Meter(s): No
- Front Media Light(s): 2 Retractable LED lamps
- Control: On/Off switch and light dimmer knob on front panel. 12 Volt triggering for remote control.
- Voltage Regulation: No
- Compliance: NRTL-C
- USB Charging: N/A
- Low Voltage Trigger: 12 V, In/Out
- Dimensions (HxWxD): 4x17x14.75" (Standard 2 RU height without feet)
- Weight: 15 lbs
- Power Consumption: 12 Watts for display and control circuits independent of actual load
- AC Protection
- AC Protection Technology: Extreme Voltage Shutdown
- Series Multi-Stage Protection
- Non-sacrificial protection with zero ground contamination
- Under-Voltage Shutoff: 85V
- Over-Voltage Shutoff: 140V ±3V
- Maximum Current Rating: 15 (Amps)
- Initial Clamping Level: 188 VAC peak @ 3,000 Amps
- Filtration
- Filtration Technology: LiFT
- Filtration Rating
- >40 dB from 10Khz. – 100 kHz.
- >80 dB from 100 Khz. _ 1GHz.
- (Linear attenuation curve from 0.05 _ 100 ohms line impedance)
- Signal Line Protection1 Tel
- 3 Cable/Satellite
- Shipping Info
- Dimensions (LxWxH): 21.5x19.6x8.2"
- Weight: 20.3 lbs
