- Base Station
- Interfaces
- 2 antenna interfaces
- 4-Pin XLR male DC input
- 3.5mm headset interface
- RJ45 interface 4 wire audio interface
- Double USB Type-A interfaces
- USB Type-C interface
- Power Supply Mode: 7~36V DC; F970 battery (typical)
- Frequency Response: 300Hz-4KHz
- Signal to Noise Ratio: >50dB
- Distortion: <2%
- Transmission Range: 300m between beltpack and base station
- Frequency Bandwidth: 1.9GHz
- Modulation Mode: GFSK
- Transmission Power: Max 24dBm
- Receiver Sensitivity: ≤93dBm
- Bandwidth:1.728MHz
- Power Consumption: <4W
- Dimensions (LxWxH): 220x170x50mm
- Net Weight: around 1400g
- Temperature Range
- Working Status: 0~+40°C
- Storage Condition: -20~+60°C
- Interfaces
- Beltpack
- Interfaces
- 2 antenna interfaces
- 3.5mm headset interface
- 3.5mm TALLY out interface
- USB Type-C interface
- Power Supply Mode: 1600mAh polymer lithium battery
- Frequency Response: 300Hz-4KHz
- Signal to Noise Ratio: >50dB
- Distortion: <2%
- Transmission Range: 300m between beltpack and base station
- Frequency Bandwidth: 1.9GHz
- Modulation Mode: GFSK
- Transmission Power: Max 24dBm
- Receiver Sensitivity: ≤93dBm
- Bandwidth:1.728MHz
- Power Consumption: <0.7W
- Dimensions (LxWxH): 100x58x22mm
- Net Weight: around 180g
- Temperature Range
- Working Status: 0~+40°C
- Storage Condition: -20~+60°C
- Interfaces
