Specifications
Dimensions
Dimensions (WxHxD)
7.1" x 5.2" x 3.1"
Electrical
Power Supply Adapter
12V DC 2A
Power Supply Interface
DC 12V 1.2A
Audio
Audio Interface
USB 2.0 Plug and Play
Optics
Lens Zoom
10X Optical Zoom f=4.7-47mm F1.6
Connectivity
Input Power
24W (max)
Construction
Material
aluminum, plastic
Environmental
Operating Temperature
32°F to 113°F (0°C to 45°C)
Shipping
Weight
1.41 pounds
General
Video CMOS Sensor
1/2.8” CMOS, 2.1 Mega Pixel
Resolutions
1080p-30/25, 720p-30/25, SVGA, VGA
Frame Rate
Up to 30fps (MJPEG)
Field of View
8° (tele) to 60° (wide)
Pan Movement
±175°
Tilt Rotation
up 90°, down 30°
Presets
64 presets
Microphone Array
dual mics on front of camera base
Pickup Range
360° up to 16.5 ft (5m)
Video Interface
USB 2.0 UVC
Controller Signal Interface
USB 2.0 Virtual Com Port (VISCA, PelcoD)
Controller Baud Rate
9600, 38400 bps
Power
Input Voltage
12V DC (10.5 - 14V DC)
Indicators
Processing
Advanced Auto Gain and Noise Control
