- Conductors
- Number: 8 (4 shielded pairs)
- Details: 1/0.57mm Solid Bare Copper
- Size: 23 AWG
- Electrical and Mechanical Characteristics
- Conductor DC Resistance: < 75 Ω/km
- Shield DC Resistance: < 100 Ω/km
- Capacitance Between Conductors: 12.3 pF/ft
- Capacitance Between Conductors/Shield: 23.8 pF/ft
- Skew Delay: < 6nS@100m
- Impedance: 100Ω
- Voltage Breakdown: 500 V
- Flex Life: ≥ 13,000
- Applicable Temperature: -4°F ~ +140°F (-20°C ~ +60° C)
- Peak Temperature: -40°F ~ +158°F (-40°C ~ +70° C)
- Insulation
- Material: FPE
- Colors
- White/Orange
- Orange
- White/Green
- Blue
- White/Blue
- Green
- White/Brown
- Brown
- Shield
- Details: Braided Magnesium Alloy & Aluminum Foil
- Construction: 16*4/0.10 (Shield continuity is present between both ends of the cable.)
- Jacket
- O.D.: 8.0 mm
- Material: PVC
- Color: blue
- Drain Wire
- Details: 1/.40 TC
